Belliss & Morcom
A leader in high-pressure compressed air. A revolutionary motor directly connected to the compressor ensures high performance and measurable energy savings. A solution designed for continuous operation—without compromising productivity.
Belliss & Morcom VH, WH
Every cubic meter of compressed air counts In a competitive industrial environment, every step toward greater efficiency matters—every cost saving, every output, every second of the production cycle. Based on our many years of experience with Belliss & Morcom compressors, we can confidently say that their technology not only takes these demands into account but also actively meets them.
A well-thought-out combination of design solutions and technical improvements delivers measurable benefits:
- lower energy consumption,
- lower operating and total cost of ownership
- Rollers with a 45° or 60° angle allow for dynamic balancing of the unit and almost completely eliminate external vibrations
- A unique motor directly connected to the compressor ensures 100% power transfer
- and exceptional stability in compressed air supply, even under the most demanding operating conditions.
VH Models: Technical Specifications
-
Capacity: 420 to 1,500 m³/h @ 40 barg / 247 to 882 cfm @ 580 PSIG
-
Power: 75 to 242 kW / 101 to 325 HP
-
Loss-free direct drive – "shaftless" motor
-
Oil-free operation
-
Water-cooled engine (customization)
-
3-stage compression
-
Capacity control: 0% → 50% → 100%
-
Selectable maximum speed: 590 to 985 rpm
WH Models: Technical Specifications
The Belliss & Morcom WH series of compressors is designed for applications requiring high volumes of oil-free air, such as PET bottle manufacturing. This series utilizes energy-efficient technologies and components that ensure high performance at low operating costs.
Performance Overview:
-
Capacity: 1,680 to 3,200 m³/h @ 40 barg / 989 to 1,883 cfm @ 580 PSIG
-
Power: 258 to 505 kW / 346 to 677 HP
-
Loss-free direct drive – "shaftless" motor
-
Oil-free operation
-
Water-cooled engine (customization)
-
3-stage compression
-
Capacity control: 0% → 50% → 100%
-
Maximum speed: 735 rpm
-
Fully balanced operation
Why Belliss Morcom, and why choose us?
Belliss & Morcom compressors offer a combination of high reliability, long service life, and low operating costs. They are designed for demanding applications such as PET packaging production and deliver high performance even at extreme pressures. Thanks to their optimal energy efficiency and ease of maintenance, they are the ideal solution for industrial operations that require continuous operation. In addition to a guaranteed five-year warranty on the compressors, we offer comprehensive technical support and authorized service, ensuring trouble-free and efficient operation throughout the equipment’s service life.
Cost savings
Example
An example for the Belliss & Morcom VH21 compressor (40 bar, 180 kW power input), which runs continuously 24 hours a day.
-
Energy
Energy consumption accounts for the largest portion of operating costs. With a power consumption of 180 kW, 24-hour operation, and an electricity rate of 2.50 CZK/kWh, the annual electricity costs amount to:
180 kW × 24 hours × 365 days × 2.50 CZK/kWh = 3,942,000 CZK per year -
Maintenance
Regular maintenance is essential for ensuring the compressor’s longevity and reliability. It includes replacing worn parts, inspecting seals, monitoring energy consumption, and performing predictive diagnostics.
Maintenance performed by professionals costs approximately 520,000 CZK per year. -
Investment
The compressor itself (excluding accessories and installation) costs CZK 3,078,720 excluding VAT. Assuming a service life of 15 years, the investment can be amortized as follows:
3,078,720 CZK ÷ 15 = 205,248 CZK per year
Total Cost of Ownership
More information about Belliss & Morcom compressors
To ensure maximum efficiency, compatibility, safety, and operational reliability, we offer a wide range of genuine accessories for Belliss & Morcom compressors.
An integral part of our supply and service offerings is the availability of genuine replacement parts and complete service kits. We maintain an above-standard inventory of all components so that we can respond quickly to both scheduled maintenance intervals and unexpected operational situations. We also offer a wide range of accessories, covering everything from filtration and cooling to monitoring systems and anti-vibration components.
Documents to Download
We provide our customers with comprehensive technical support, including expert advice, operator training, and prompt responses to technical inquiries. You can rely on us and turn to us at every stage of our partnership—from equipment selection to operation and maintenance. In the Downloads section, you’ll find the product catalog and other important documents for quick and easy access to information.
Request for a Compressor
By filling out this short inquiry form, you’ll help us design a compressor that meets your specific needs and requirements.
